2-In/4-Out 24/192 Audio MIDI Interface
Key Features
- 24-bit/192kHz resolution for professional recording and monitoring
- Hi-Speed USB circuitry for fastest connection, with class-leading round-trip latency of 2.59ms*
- Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality
- VU LED meters for dialing in the perfect level
- Flexible inputs: (2) XLR+¼” TRS combo with -10dB mic pad or ¼” instrument inputs
- Use any combination of TRS combo or ¼” instrument input on the two channels:(2) TRS, (2) instrument or (1) of each
- MIDI input/output for connecting virtually any external MIDI gear
- Stereo ¼” and RCA outs with direct mono/stereo switch
- (2) RCA assignable auxiliary outputs; ¼” headphone output with independent source and level controls
- Rugged metal chassis; large central control for easy volume adjustment
- USB/Direct knob for balancing between the input signal and the computer signal
*Round trip latency is dependent on buffer settings, and computer hardware
Downloads
What’s In The Box
- AIR 192|8
- USB-C-to-USB-C Cable
- USB-C-to-USB-A Cable
- (2) 1/8" (3.5 mm) to MIDI Adapters
- Software Download Cards
- User Guide
- Safety and Warranty Manual
Specifications
Minimum System Requirements
macOS: 10.8 Class Compliant
PC: Windows 7, Windows Driver
Standard USB 2.0 or USB-C Port
20Hz – 20kHz (+/-0.1 dB) |
104dB (A-weighted) |
104dB (+1.0dBu, A-weighted) |
0.001% (1kHz, +0.8dBu, -1dBFS) |
-126dBu (150Ω, unweighted) |
+1.8dBu |
60dB |
20Hz – 20kHz (+/-0.1dB) |
101dB (1kHz, +4dBu, A-weighted) |
0.002% (1kHz, +19.7dBu, -1dBFS) |
+20.7dBu |
106dB (A-weighted) |
20Hz – 20kHz (+/-0.1dB) |
106dB (A-weighted) |
98dB (+4dBu, A-weighted) |
0.001% (1kHz, +5.8dBu, -1dBFS) |
+6.8dBu |
~1MΩ |
24dB |
20Hz – 20kHz (+/-0.1dB) |
109dB (A-weighted) |
0.003% (1kHz, -1dBFS) |
+13dBu |
20Hz - 20kHz (+/-0.1dB) |
109dB (A-weighted) |
0.003% (1kHz, -1dBFS) |
+7dBu |
101dB |
0.008% (1kHz, -1dBFS, 36mW) |
36mW (32-ohm load) |
32-ohm |
