The Essential DJ Mixer for Analog and Digital: Numark M101USB
DJs always need a dependable mixer, and the Numark M101USB fits the bill perfectly as a highly adaptable two-channel solution for virtually any DJ. This mixer allows you to get up and running quickly whether you're using a computer, turntables, or CD players. The M101USB is right at home at weddings, parties, clubs, and everything in-between, offering a durable and reliable centerpiece for your performance.
The M101USB builds on the classic M101 mixer by adding a powerful, easy-to-use USB audio interface. This allows DJs who want the option of working with their computer to seamlessly play audio from software or record their sets straight to their computer's hard drive. It’s a perfect fit for both beginners and seasoned DJs alike who want a durable USB-equipped two-channel mixer.
Beyond simply mixing, the M101USB has a built-in 2-band EQ on each channel so you can fine-tune your mix depending on the room or the tracks themselves. Two pairs of switchable Phono/Line inputs are included, along with a replaceable crossfader, a ¼” mic input for announcements, and a stereo RCA line output for connection to any amplifier or powered speakers. With its legendary industrial-grade durability, the M101USB is ready for any gig.
Key Features:
-
2-Channel Rack-Mountable Mixer: A compact and highly adaptable mixer with a durable, industrial-grade build.
-
Built-in USB Audio Interface: Play audio directly from or record your mix to a Mac or PC with a single USB cable.
-
Versatile Inputs: Two pairs of switchable Phono/Line inputs allow for the connection of turntables, CD players, and other line-level devices.
-
2-Band EQ Per Channel: Easily tweak your sound with dedicated Bass and Treble EQ knobs on each channel.
-
Dedicated Mic Input: Features a 1/4-inch microphone input with its own dedicated EQ for voiceovers and announcements.
-
Replaceable Crossfader: A smooth, reliable crossfader that can be easily replaced if it ever wears out.
-
Professional Outputs: A stereo RCA output allows for easy connection to amps, powered speakers, or another mixer.
-
Class Compliant: Instantly compatible with every current and future version of Mac OS X and iOS and with Windows (98SE and up) operating systems.
Technical Specifications:
-
Inputs:
-
Line: 10kΩ input impedance
-
Phono: 47kΩ input impedance
-
Mic: 600Ω input impedance
-
-
Outputs:
-
Line: 7.35 V RMS max
-
Headphone: 0.5W into 47Ω
-
-
Signal to Noise Ratio:
-
Line: > 97 dB
-
Phono: > 81 dB
-
Mic: > 96 dB
-
-
Frequency Response:
-
Line: 20 Hz – 20 kHz (±0.5dB)
-
Phono: ±1dB (with controlled attenuation at 20 Hz)
-
-
Channel EQ:
-
Treble: +10 / -28 dB @ 15 kHz
-
Bass: +12 / -32 dB @ 60 Hz
-
-
Dimensions (W x D x H): 9.0" x 10.3" x 4.1" (229 x 262 x 104 mm)
-
Weight: 6.4 lbs (2.9 kg)
What's in the box:
-
M101USB Mixer
-
Power Supply
-
USB Cable
-
Quickstart Guide
