Achieve powerful and clear sound for any permanent installation with the Proel LTX10A. This versatile 10-inch active speaker combines high-quality components, advanced signal processing, and flexible mounting options, making it the perfect solution for venues, commercial spaces, and more.
Detailed Product Description:
Professional Sound for Fixed Installations
The Proel LTX10A is a high-performance active loudspeaker engineered specifically for the demands of fixed installations. Whether you are outfitting a conference room, a house of worship, a retail space, or a live performance venue, the LTX10A delivers powerful, clear, and consistent sound in a durable and versatile package. Housed in a rugged plywood enclosure, it is built to perform reliably day after day.
Advanced Acoustic Design
The LTX10A features a 2-way vented design with a high-excursion 10” woofer and a 1” compression driver. This combination, powered by a 600W peak Class D and Class AB bi-amplification system, delivers a deep, tight bass response and crisp, clear high frequencies. The symmetrical 90°x90° dispersion horn ensures wide and even sound coverage, providing an excellent listening experience for the entire audience, whether the speaker is mounted vertically or horizontally.
Optimized Performance and Protection
A sophisticated pre-amp section with active EQ and crossover filters allows for precise tuning of the system's sound. To ensure reliability even at high volumes, the LTX10A includes independent limiter circuits for the high and low frequencies. This advanced protection prevents distortion and safeguards the loudspeaker components, guaranteeing a long operational life. With multiple M10 suspension points and a standard pole mount, installation is simple and flexible.
Key Features:
-
Installation-Ready Design: Multiple M10 suspension points and accessories for easy wall or ceiling mounting.
-
Powerful Bi-Amplification: 600W peak power from a lightweight Class D (LF) and Class AB (HF) amplifier module.
-
Wide and Even Coverage: A 90° x 90° symmetrical horn provides constant sound dispersion for large audiences.
-
High-Quality Transducers: Features a 10” woofer with a 2” voice coil and a 1” compression driver.
-
Advanced DSP: Sophisticated pre-amp with crossover filters and active EQ for optimal sound.
-
Built-in Limiter Protection: Independent limiters for high and low frequencies prevent distortion and protect the speaker.
-
Durable Plywood Enclosure: Rugged construction designed for the demands of commercial installations.
-
Portable Flexibility: Includes a standard 35mm pole socket for use with speaker stands.
What's in the Box:
-
1 x Proel LTX10A Active Speaker
-
1 x Mains Power Cable
-
1 x User Manual
Technical Specifications:
