Cardioid Instrument Microphone
Features
Contoured frequency response for clean, instrumental reproduction and rich vocal pickup
Professional-quality reproduction for drum, percussion, and instrument amplifier miking
Uniform cardioid pickup pattern isolates the main sound source while reducing background noise
Pneumatic shock-mount system cuts down handling noise
Extremely durable under the heaviest use
Specification
Type : Dynamic
Frequency Response: 40 to 15,000 Hz
Polar Pattern: Cardioid
Sensitivity (at 1,000 Hz Open Circuit Voltage):
-54.5 dBV/Pa (1.85 mV) 1 Pa = 94 dB SPL
Impedance: 150 Ohm
Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Case: Dark gray, enamel-painted, die cast metal; matte-finished, silver colored, spherical steel mesh grille
Connector: 3-pin XLR
Net Weight: 298g
Dimensions: 162 mm L x 51 mm W
Frequency Response: 40 to 15,000 Hz
Polar Pattern: Cardioid
Sensitivity (at 1,000 Hz Open Circuit Voltage):
-54.5 dBV/Pa (1.85 mV) 1 Pa = 94 dB SPL
Impedance: 150 Ohm
Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Case: Dark gray, enamel-painted, die cast metal; matte-finished, silver colored, spherical steel mesh grille
Connector: 3-pin XLR
Net Weight: 298g
Dimensions: 162 mm L x 51 mm W
| Sensor type | Moving coil |
|---|---|
| Frequency range | 40 to 15,000 Hz |
| Sensitivity (dBV/Pa) | -54.5 dBV/Pa |
| Sensitivity (mV/Pa) | 1.88 mV/Pa |
| Style | Handheld Microphone |
| Feature | Noise Canceling High Sensitivity Omnidirectional |
| Pick Up mode | Cardioid |
| Application | Live performance, studio recording, stage performa |
