The Ultimate Compact DJ Mixer: The DAP CORE MIX-2 USB
The DAP CORE MIX-2 USB is a basic 2-channel analogue DJ mixer that packs a professional punch. It features 4 analogue inputs and 2 independent USB-Audio interfaces, making it incredibly easy to connect your laptop and route the output of your DJ software directly through the mixer. The headphone output includes a low-tone control, allowing you to adjust the sound to your preference.
Designed for performance and durability, both the channel and cross-faders have selectable curves. All potentiometers are locked below the surface for extra stability, and a separate fader print board ensures easy maintenance. A standout feature is the built-in MP3 module, which can record and play back your live performance directly to a USB or SD device, making it a versatile tool for any DJ.
Key Features:
-
2 Built-in USB Audio Interfaces: Easily connect two laptops (PC/Mac) for seamless DJ handovers or complex digital setups.
-
High-Quality Components: A robust metal housing and high-quality components ensure stability and a long service life.
-
60 mm VCA Faders: Smooth and reliable 60 mm faders for precise level control.
-
MP3/USB/SD Recorder & Player: Record your live sets directly to a USB stick or SD card, and play back tracks from the same sources.
-
LED VU Meter for Each Channel: Keep an eye on your levels with dedicated LED metering for each channel.
-
Bluetooth Connectivity: Features a Bluetooth 5.0 receiver with a 20m range for wireless audio playback.
Technical Specifications:
-
Inputs:
-
Mono Inputs: 1 (3-pin XLR, TRS balanced 6.3 mm)
-
Stereo Inputs: 4 (RCA)
-
Phono Inputs: 1 (RCA)
-
-
Outputs:
-
Main Outputs: 2 (3-pin XLR, RCA)
-
Monitor Outputs: 1 (RCA)
-
Headphone Output: 1 (TS balanced 6.3 mm)
-
Record Output: 1 (RCA)
-
-
Audio Interface:
-
USB Type: 2.0
-
Sample Rate: 48 kHz
-
Channels: 2 In / 2 Out
-
-
Media Player:
-
Supported Files: MP3, WAV
-
Max Storage Size: 64 GB
-
-
Audio Specifications:
-
THD: < 0.1%
-
Frequency Response: 20 Hz - 20,000 Hz
-
-
Sound Editing:
-
Channel EQ: 3 Bands (70, 1,000, 13,000 Hz)
-
Microphone EQ: 3 Bands (120, 800, 5,000 Hz)
-
-
Mechanical Specifications:
-
Dimensions (W x H x L): 11.8" x 3.5" x 9.4" (300 x 88 x 240 mm)
-
Weight: 7.5 lbs (3.4 kg)
-
Housing: Metal
-
In the Box:
-
DAP CORE MIX-2 USB Mixer
-
IEC cable
