RANE ONE MKII: Professional Motorized DJ Controller



The RANE ONE MKII is a performance-ready, motorized DJ controller built to give professional DJs unparalleled creative freedom in any live set. Designed for flexible, open-format workflows, the MKII features motorized, high-torque platters that provide the tactile response and technical precision professional DJs demand.



Key Features



• Fader FX: Utilize volume faders as linear controls for Pitch, Filter, Roll, and Ring Modulator FX, along with four distinct tone generators.

• Dynamic Internal FX Suite: Access 29 meticulously crafted internal hardware effects with a dedicated display, offering an extensive palette for smooth transitions and dynamic mixes in clubs, bars, and high-energy live events.

• Stems Controls: New to the MKII, these controls provide greater creative flexibility, enabling easy live mixing and modification of tracks. Effortlessly isolate or remove acapellas and instrumentals, or add FX or Rolls to vocals, melody, bass, or drums of a track.

• Serato DJ Pro Unlocked: The RANE ONE MKII unlocks the powerful Serato DJ Pro software, expanding how Stems can be incorporated into your live set.

• Customizable Controls: Tailor the controller to your individual style with customizable pad modes, a dedicated sampler knob, tension-adjustable PRECISION FEEL channel faders, and a MAG FOUR crossfader for accurate mixing.

• Professional-Grade Sound & Connectivity: Ensures seamless integration into any setup, allowing DJs to focus entirely on their performance.

• Sleek Design: A clean, modern white finish enhances any DJ setup and improves control surface visibility.

• Versatile and Durable: Built to last, the RANE ONE MKII is the ultimate performance tool for professional DJs.



Extended New Feature:



1.Dynamic Internal FX Suite:



Offers 29 meticulously crafted internal effects, providing DJs with an extensive palette of sonic possibilities. From subtle enhancements to transformative soundscapes and fader-controlled transition FX, this suite elevates the creative potential of every performance.



2.      Stems Controls for Creative Flexibility:



o   Acapella and Instrumental Buttons: Effortlessly isolate vocals or instrumentals for unique transitions and remixes in real time.

o   Stems Level Control: Seamlessly adjust the balance of individual audio elements with the EQ knobs.

o   Stems Pad Mode: Quickly mute and apply FX to individual stem parts.

o   Stems Roll Pad Mode: Stem Roll pad mode is a new performance pad mode that allows the user to apply loop rolls to individual or multiple stem parts.

o   Stems FX Pad Mode: Stem FX pad mode is a new performance pad mode that allows users to apply Echo Out, Roll Out, Brake, or Delay FX to individual or multiple stem parts.



3.      Secondary Pad Buttons:

Access multiple pad modes simultaneously with dedicated secondary buttons above the platter, streamlining performance workflows and unlocking greater creative freedom without sacrificing simplicity.



4.      Channel FX:

The Filter knob on each deck can access four different Channel FX, providing hands-on control of the Filter, Filter Roll, Flanger, and Noise FX.



5.      PRECISION FEEL Channel Faders:

Experience a new level of tactile precision with ultra-smooth, accurate, and tension-adjustable control that empowers intricate and dynamic mixing.



6.      Stunning White Colorway:

The MKII introduces a stylish white finish, combining aesthetics with function. This makes it an eye-catching centerpiece of any DJ setup while improving control surface visibility.



Changes from Current Model

·       Added DSP, OLED, joystick, and HW/SW button for FX control



·       Add Channel FX buttons to enable/disable Channel FX and select the FX



·       Touch strips replaced with 4 buttons to access multiple pad modes simultaneously—performance pads beneath the platters can also be split to access 2 pad modes, so users can access 3 different pad modes on each deck



·       Added a mode button for the secondary pad group



·       Repurposed the Slip button for Acapella



·       Repurposed the Censor button for Instrumental



·       Repurposed the Range/Keylock button for Slip



·       Replaced the standard channel/up faders with PRECISION FEEL faders



·       Added dedicated Sampler volume knob on front panel



·       Colorway: White

Technical Specifications:



·       Digital Audio

o   Converters: Cirrus Logic, 24-bit PCM, 48 kHz

o   Digital Signal Processing: 32-bit, floating point, double precision

o   Dynamic Range (A-weighted, unity gain):

§  ADC: 113 dB

§  DAC: 113 dB

§  CD Input to Analog Output: 110 dB

§  CD Input to USB Output: 113 dB

§  USB Input to Analog Output: 113 dB

·       Inputs

o      Microphone 1/2 (Combo XLR/1/4” [6.35 mm] TRS, Mic/Line switchable)

§  Analog Gain: 25 dB

§  Maximum Input: 110 mV

§  Gain Trim: Off to +26 dB (unity at center)

§  Tone Control: 2-band

o      Aux Input (RCA stereo pair)

§  Maximum Input: 4 Vrms

§  Dynamic Range (A-weighted): 114 dB

§  Gain Trim: Off to +12 dB

§  Tone Control: 2-band

o      CD/Phono Inputs 1/2 (RCA stereo pairs, switchable)

o   CD

·       Maximum Input: 4 Vrms

·       Gain Trim: Off to +12 dB

·       Tone Control: 3-band, full-cut to +10 dB

·       THD+N (20 kHz BW @ 1 kHz): 0.004%

o   Phono

·       RIAA Curve: +/- 0.25 dB

·       Gain (@ 1 kHz): 31.5 dB

·       Maximum Input (@ 1 kHz): 106 mV

·       Dynamic Range (A-weighted): 102 dB

·       Outputs

o   Main Outputs (XLR)

§  Gain Trim: Off to 0 dB

§  Maximum Output: 8 Vrms

§  THD+N (20 kHz BW @ 1 kHz): 0.004%

§  Frequency Response: Flat

o   Booth Outputs (XLR)

§  Gain Trim: Off to 0 dB

§  Maximum Output: 8 Vrms

§  THD+N (20 kHz BW @ 1 kHz): 0.004%

§  Frequency Response: Flat

o   Master Outputs (RCA stereo pair)

§  Maximum Output: 4 Vrms

§  THD+N (20 kHz BW @ 1 kHz): 0.004%

§  Frequency Response: Flat

o   Headphone Outputs (1/4”/6.35 mm and 1/8”/3.5 mm TRS)

§  Maximum Output Voltage: 4 Vrms (no load)

§  Output Power: 50 mW (50 ohms)

§  Dynamic Range (A-weighted): 108 dB



·       Pads

o   16x multi-color back-lit pads (8 per deck, 10 modes each)

o   Secondary performance pad buttons with 8 pad modes



·       Faders

o   (1) MAG FOUR tension-adjustable crossfader with independent Contour and Reverse controls

o   (2) PRECISION FEEL tension-adjustable faders with Contour knob and Reversal switches

·       Connectors

o   (2) XLR outputs (Main)

o   (2) XLR outputs (Booth)

o   (1) RCA stereo output pair (Master)

o   (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1-2)

o   (2) RCA stereo input pairs (Deck 1-2)

o   (1) RCA stereo input pair (Aux)

o   (1) 1/4” (6.35 mm) TRS output (Headphones)

o   (1) 1/8” (3.5 mm) TRS output (Headphones)

o   (2) USB Type-B ports

o   (1) IEC power cable input

·       Power

o   Connection: IEC

o   Voltage: 100–240V, 50/60 Hz

o   Consumption: 50 W

·       Dimensions

o   W x D x H: 26.5” x 13.6” x 4.9” (674 x 345 x 124.3 mm)



·       Weight

o   24.56 lbs. (11.14 kg)
