Deep, Powerful Bass with Intelligent Processing: The Proel DIVASUB18A
The Proel DIVASUB18A is a high-performance active subwoofer designed to be the perfect low-frequency extension for any full-range PA system, especially the Proel DIVA series. This subwoofer delivers a deep, powerful, and exceptionally clean bass response, making it ideal for live bands, mobile DJs, and fixed installations in clubs, bars, and event venues.
At the heart of the DIVASUB18A is a massive 1500W peak Class D amplifier, coupled with a high-excursion 18-inch woofer. The sound is precisely shaped by the powerful CORE LT 24-bit DSP, which provides sophisticated algorithms for protection, dynamic EQ, and 4 selectable presets (LIVE, DANCE, SUB, USER) to perfectly tailor the sound for any application.
Built for the rigors of professional use, the DIVASUB18A is housed in a rugged and lightweight plywood cabinet with a scratch-resistant polyurethane paint finish. Its comprehensive control panel, stereo crossover, and phase reverse switch allow for perfect integration into any sound system, providing a solid and authoritative low-end foundation for your music.
Key Features:
-
1500W Active Subwoofer: A powerful Class D amplifier with SMPS delivers 1500W of peak power for a deep and impactful bass response.
-
High-Excursion 18" Woofer: A custom-designed 18-inch woofer with a 3-inch voice coil provides an extended low-frequency response and high SPL.
-
CORE LT 24-bit DSP: An advanced digital signal processor with 4 selectable EQ presets (LIVE, DANCE, SUB, USER) for optimal sound in any situation.
-
Stereo Crossover: An integrated stereo electronic crossover with selectable frequency allows for perfect integration with full-range speakers.
-
Durable and Lightweight Cabinet: A rugged plywood cabinet with a scratch-resistant polyurethane finish and two metal handles for easy transport.
-
Phase Reverse Switch: A phase switch allows for perfect alignment with your main speakers, regardless of their position.
-
Flexible Connectivity: Features two combo XLR/Jack inputs and two XLR outputs for both linked and crossed-over signals.
-
Pole Mount Socket: A standard M20 pole mount socket on the top allows for the easy mounting of a satellite speaker.
Technical Specifications:
-
System type: Vented enclosure subwoofer
-
Loudspeaker: 18” woofer with 3” VC
-
Amplifier Continuous Power: 750 W
-
Peak Power: 1500 W
-
Frequency response: 35 Hz - 160 Hz
-
Max SPL: 128 dB
-
Inputs: 2 x NEUTRIK COMBO
-
Outputs: 2 x NEUTRIK XLR-M
-
Controls: Level, PRESET selector, DELAY selector, PHASE reverse
-
DSP: 24-bit / 96kHz CORE LT
-
Power Supply: 230 VAC or 120 VAC 50/60 Hz
-
Construction: Plywood with anti-scratch black paint
-
Pole holder: 1 x top M20
-
Dimensions (W x H x D): 20.9" x 23.6" x 22.6" (530 x 600 x 575 mm)
-
Weight: 68.3 lbs (31 kg)
What's in the box:
-
DIVASUB18A Active Subwoofer
-
Power Cord
-
User Manual
