Compact Power for Professional Installation: The Proel LTX10A
The Proel LTX10A is a 2-way active loudspeaker designed for professional sound reinforcement in a wide variety of fixed installations. Housed in a lightweight yet ultra-durable polypropylene cabinet, this speaker delivers a powerful and clear sound that belies its compact size. It’s the perfect solution for venues such as bars, pubs, schools, and houses of worship, as well as for portable PA applications.
The LTX10A features a high-performance bi-amplification module, combining a 500W Class-D amplifier for the low frequencies and a 100W Class-AB amplifier for the high frequencies, ensuring an efficient and dynamic performance. The heart of the speaker is a 10-inch woofer and a 1-inch compression driver, which together provide a full and balanced sound.
With its integrated digital signal processing (DSP), the LTX10A offers 4 selectable EQ presets (Standard, Vocal, Floor, Anti-feedback), allowing you to quickly optimize the speaker's sound for any application. The cabinet’s asymmetrical design allows it to be used as a stage monitor, and multiple M10 flying points provide flexible installation options.
Key Features:
-
600W Bi-amplified 2-Way System: A powerful combination of a 500W Class-D (LF) and 100W Class-AB (HF) amplifier delivers a clear and dynamic sound.
-
High-Quality Components: Features a 10-inch woofer with a 2-inch voice coil and a 1-inch high-definition compression driver.
-
Built-in DSP with 4 EQ Presets: Easily tailor the sound to your application with four selectable EQ presets (Standard, Vocal, Floor, Anti-feedback).
-
Versatile Connectivity: A comprehensive input section with two MIC/LINE combo inputs, a stereo mini-jack input, and an XLR MIX output.
-
Durable and Lightweight Cabinet: A rugged polypropylene cabinet with an ergonomic handle makes the speaker both durable and easy to transport.
-
Flexible Installation: Can be used as a stage monitor thanks to its asymmetrical design, and features a 35mm pole socket and 4 M10 flying points.
-
Independent Level Controls: Each input channel has its own dedicated level control for easy mixing.
-
Signal and Clip Indicators: Front and rear LED indicators for signal presence and clip/limit status.
Technical Specifications
-
System type: 2-way vented enclosure
-
HF Device: 1” compression driver
-
LF Device: 10” woofer with 2” VC
-
Frequency response: 60Hz - 20kHz
-
Max SPL: 123 dB
-
Amplifier: 500W Class D (LF) + 100W Class AB (HF)
-
DSP: 4 EQ presets (Standard, Vocal, Floor, Anti-feedback)
-
Inputs: 2 x MIC/LINE (COMBO), 1 x STEREO (mini-jack)
-
Outputs: 1 x MIX OUT (XLR-M)
-
Controls: CH1/CH2 level, LINE/MIC selector, PRESET selector, MASTER level
-
Housing: Polypropylene
-
Mounting: 1 x top handle, 1 x side handle, 36mm pole socket, 4 x M10 flying points
-
Dimensions (W x H x D): 12.6" x 20.9" x 11.8" (320 x 530 x 300 mm)
-
Weight: 27.6 lbs (12.5 kg)
What's in the box:
-
LTX10A Active Loudspeaker
-
Power Cord
-
User Manual
